    80A - 98A Polyurethane Round Belt For Printing And Packing Machine

    Ask Lasest Price
    Brand Name : jiuna
    Model Number : Diameter 2mm-20mm
    Certification : ROHS
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 100.000 meters per Month
    Delivery Time : Within 5 working days After receipt of your deposit
    • Product Details
    • Company Profile

    80A - 98A Polyurethane Round Belt For Printing And Packing Machine

    80A - 98A Polyurethane Round Belt For Printing And Packing Machine

    Product Description

    TPU Belts
    Specifications
    Smooth Round Belt, Rough Round Belt, V Belt, Ridge Belt, Hexangular Belt, Top Ridge Belt, Supergrip belt, T Belt, Flat Belt, Parallel Belt
    Details:
    (1)Thermoplastic polyurethane material, easy to be melted jointed
    (2)Reinforced by Polyester Cord or Steel Cord
    (3)Temperature range -35 - 80
    (4)Shore A hardness range 80A - 98A
    (5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
    (6)Round Belt:
    Round Belt Dia. Is from 2mm to 30mm
    Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.
    (7)V-belt
    Specifications include the A, B, C, D, M, Z type
    Widely used in ceramic industry, excellent wear resistance
    (8)Pentagon Belt, Septangular Belt, Suppergrip belt
    Specifications include A, B, C three type
    (9)Hexagonal Belt
    Specifications include C
    (10)Parallel Belt
    Including A, B two specifications

    ApplicationsMainly used in transmission and distribution products for the textile, clothing, food, packaging, printing, machinery, electronic, glass, chemicals, automobiles, beverages, furniture, toys, paper and other industries; Especially in the ceramic industry, widely used in the glazing Lines, transmission lines, polishing line etc.
    Normal specifications including Z, M, A, B, C, D and the Pentangular Belt including A, B, C type, pentagonal belt normally used in the production line's corner.

    Items No. φleast radius of gyrationstretch rateMaximum tensile rateHardnesslength of rolled

    Dia.

    (mm)

    InmmStretching rateKgLbs

    Hardness

    (A)

    Roll

    (m)

    2mm0.79201.5-3%0.30.790 A400
    3mm0.98251.5-3%0.71.690 A400
    4mm1.38351.5-3%1.22.785 A200
    15mm4.721201.5-3%17.739.085 A30
    18mm5.711451.5-3%25.456.085 A30
    20mm6.301601.5-3%31.369.085 A30

    Products introduction:

    Urethane round belts are elastomeric belts for power transmission application.

    Having most metric sizes (2mm to 20mm) and standard O-ring sizes.

    Polyether and Polyurethane round belts have best resilience of any elastic material.

    Polyester product has good wear resistance, its wear resistance is 3.5 times of common

    plastic and rubber.


    Service commitment:

    “Quality for keeping going ,Credit to win the world”


    80A - 98A Polyurethane Round Belt For Printing And Packing Machine80A - 98A Polyurethane Round Belt For Printing And Packing Machine80A - 98A Polyurethane Round Belt For Printing And Packing Machine

    Quality 80A - 98A Polyurethane Round Belt For Printing And Packing Machine for sale
