    Low compression Polyurethane Round Belt / Smooth Round Drive Belts

    Ask Lasest Price
    Brand Name : Jiuna
    Model Number : Diameter 2~20 mm
    Certification : ROHS
    Payment Terms : T/T, 50% payment in advance ,50% balance before shipment
    Supply Ability : 96.000 meters per Month
    Delivery Time : Within 5 working days After receipt of your deposit
    • Product Details
    • Company Profile

    Low compression Polyurethane Round Belt / Smooth Round Drive Belts

    Polyurethane belting of introduction:



    We offer a complete line of Polyester and Polyurethane Round belts for use in industrial machines. And In the conveyance of products ranging from transport machine,conveyor machine to glass and tile. Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers,kelver,steel cord. Also can joint belt to O-ring . supply the connecting tools & Accessories for polyurethane belts , including clamp ,the Electric Iron and Knife , Connecting methods is hotpress welding , overlap welding .
    The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .

    Features:
    Outstanding abrasion resistance
    High tensile and tear strength
    Resistance to oils, fuels,and oxygen
    Good weatherability and high impact resistance
    Low compression set

    Application:
    Newspaper conveying,
    Packing machines,
    Ceramic and stoneware processing plants,
    Floor and roof tiles conveying,
    Wood Working machineries,
    Textile machines,
    Paper industry machines,
    Food grading machines, other food processing machines.


    Items NO.Φ

    Least radius of gyration

    Stretching rate

    Maximum tensile rate

    Hardness

    Length of rolled

    DIA(mm)

    In

    mm

    %

    Kg

    Lbs

    Shore( A)

    Length of rolled
    ( m )

    2mm

    0.79

    20

    1.5-3%

    0.3

    0.7

    95

    400

    2.5mm

    0.87

    22

    1.5-3%

    0.4

    0.9

    95

    400

    3mm

    0.98

    25

    1.5-3%

    0.7

    1.6

    90

    400

    3.5mm

    1.18

    30

    1.5-3%

    0.95

    2.1

    90

    400

    4mm

    1.38

    35

    1.5-3%

    1.2

    2.7

    90

    200

    5mm

    1.57

    40

    1.5-3%

    2.0

    4.3

    90

    100

    6mm

    1.97

    50

    1.5-3%

    3.2

    7.0

    90

    100

    7mm

    2.17

    55

    1.5-3%

    4.1

    9.0

    90

    100

    8mm

    2.56

    65

    1.5-3%

    5.0

    11.0

    90

    100

    9mm

    2.95

    75

    1.5-3%

    6.8

    15.0

    90

    50

    10mm

    2.95

    75

    1.5-3%

    7.7

    17.0

    90

    50

    12mm

    3.94

    100

    1.5-3%

    12.2

    27.0

    90

    30

    15mm

    4.72

    120

    1.5-3%

    17.7

    39.0

    90

    30

    18mm

    5.71

    145

    1.5-3%

    25.4

    56.0

    90

    30

    20mm

    6.30

    160

    1.5-3%

    31.3

    69.0

    90

    30



    Low compression Polyurethane Round Belt / Smooth Round Drive BeltsLow compression Polyurethane Round Belt / Smooth Round Drive Belts
