    PU Polyurethane Extruded V Belt Transmission Belt

    Ask Lasest Price
    Brand Name : VOLTA
    Model Number : A-13 ,B-17 ,C-22
    Certification : ROHS
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 96,000,00 m per month
    Delivery Time : Within 5 working days After receipt of your deposit
    • Product Details
    • Company Profile

    PU Polyurethane Extruded V Belt Transmission Belt


    PU Polyurethane Extruded V Belt Transmission Belt


      We offer a complete line of PU Polyurethane Extruded V Belt Red &100m roll for use in transmission industrial machines. And In the conveyance of products ranging from transport machine,conveyor machine to glass and tile. Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers. Also can welding belt to O-ring . supply the connecting tools & Accessories for polyurethane belts , include clamp ,the Electric Iron and Knife , Connecting methods is hotpress welding , overlap welding .


      The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .


      Features:

      • Outstanding abrasion resistance
      • High tensile and tear strength
      • Resistance to oils, fuels,and oxygen
      • Good weatherability and high impact resistance
      • Low compression set

      Application:

      • Newspaper conveying,
      • Packing machines,
      • Ceramic and stoneware processing plants,
      • Floor and roof tiles conveying,
      • Wood Working machineries,
      • Textile machines,
      • Paper industry machines,
      • Food grading machines, other food processing machines

      PU V belt


      (1) Thermoplastic polyurethane material, easy to be melted jointed.

      (2) Reinforced by Polyester Cord or Steel Cord.

      (3) Temperature range -35 celsius degree - 80celsius degree.

      (4) Shore A hardness range 80A - 98A.

      (5) With excellent resistance to flex, abrasion resistance, easy jointed and Other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.

      (6) Round Belt:
      Round Belt Dia. Is from 2mm to 30mm
      Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.

      (7 )V-belt Specifications include the A, B, C, D, M, Z type
      Widely used in ceramic industry, excellent wear resistance.

      (8) Pentagon Belt, Septangular Belt, Suppergrip belt
      Specifications include A, B, C three type.

      (9) Hexagonal Belt
      Specifications include C

      (10) Parallel Belt
      Including A, B two specifications

      Applications:


      Mainly used in transmission and distribution products for the textile, clothing, food, packaging, printing, machinery, electronic, glass, chemicals, automobiles, beverages, furniture, toys, paper and other industries; Especially in the ceramic industry, widely used in the glazing Lines, transmission lines, polishing line etc.
      Normal specifications including Z, M, A, B, C, D and the Pentangular Belt including A, B, C type, pentagonal belt normally used in the production line's corner.


      Specification

      X(mm)

      H(mm)

      Hardness (Shore A)

      M/rolls

      Reinforced

      A

      13

      8

      90

      30

      ·

      B

      17

      11

      90

      30

      ·

      C

      22

      14

      90

      30

      ·

      D

      32

      19

      90

      30

      ·

      M

      8

      4

      90

      50


      Z

      10

      5

      90

      50

      ·
